Megarevo 5KW Single Phase Low Voltage Hybrid Inverter

539 ~550€/pcVAT excluded

Inquiry Us Add Product

PREV: Deye SUN-12K-SG02LP2-EU Hybrid Inverter NEXT: Megarevo 6KW Single Phase Low Voltage Hybrid Inverter

Product Description

Uni Z International B.V. +39 3444606026

Uni Z International B.V. [email protected]

L1 Series 3-6kW low-voltage hybrid inverter supports simultaneous input of PV, batteries, diesel generators, power grids, and loads. It has multiple application modes, including self-consume, peak shaving and valley filling, and backup power supply. Passed CEI 0-21, VDE-AR-N 4105, IEC/EN62109-1/-2, IEC/EN62477-1, IEC/EN 61000-6-1 certification. Support multi-parallel connection. Support flexible access to diesel generators. Compatible with lead-acid and lithium-ion battery.Support on/off-grid automatic switching function to ensure uninterrupted power.

Technical specification:

Technical specification	R5KL1
PV string input
Max. power(kW)	7
Max. DC voltage(V)	550
MPPT voltage range(V)	125~500
Max.input current of single MPPT(A)	14
No. of strings per MPPT trackers	1/1
AC output
Rated output power(kVA)	5
Max. output current(A)	21.7
Grid voltage/range(V)	230/176~270
Frequency (Hz)	50 /60
Power factor	0.99guiding-0.99lagging
THDi	＜3%
AC grid type	L+N+PE
Battery
Battery voltage range(V)	40~58
Max. charging voltage(V)	58
Max. charge/discharge current(A)	95/104.2
Battery type	lithium /Lead-acid
Communication interface	CAN
EPS output
Rated power (kVA)	5
Rated output voltage(V)	230
Rated output current(A)	21.7
Rated frequency (Hz)	50 /60
Automatic switchover time (ms)	＜10
THDu	＜2%
Overload capacity	110%, 30S/120%, 10S/150%, 0.02S
General data
Battery charge/discharge efficiency	95.00%
DC Max. efficiency	97.60%
Europe efficiency	97.00%
MPPT efficiency	99.90%
Ingress protection	IP65
Noise emission (dB)	<35
Operation temperature	- 25℃～ 60℃ (Derating at 45℃)
Cooling	Natural
Relative humidity	0 ~95%（non-condensing）
Operation altitude (m)	2,000 (>2,000 Derating)
Dimensions W * D * H (mm)	550200515
Net weight (kg)	25
Topology	Non-isolated
Self-consumption at night (W)	15~25
Display and communication
Display	LCD
interface: RS485/Wifi/4G/ CAN/DRM	Yes/ Opt/ Opt/ Yes/ Yes
Safety standard	IEC/EN62109-1/-2, IEC/EN62477-1
EMC	IEC/EN 61000-6-1, IEC/EN 61000-6-3
On-grid	South Africa NRS097-2-1:2017, UK G98,G99 ,EN 50549-1
