Deye SUN-6K-SG03LP1-EU Hybrid Inverter

890~920€/pcVAT excluded

Inquiry Us Add Product

PREV: Deye SUN-5K-SG03LP1-EU Single Phase Hybrid Inverter NEXT: Deye SUN-8K-SG01LP1-EU Hybrid Inverter

Product Description

Uni Z International B.V. +39 3444606026

Uni Z International B.V. [email protected]

The Deye SUN-6K-SG03LP1-EU inverter is for residential and commercial solar systems, solar energy self-consumption, and bolstering energy independence. It efficiently manages the energy from PV generation to battery storage, ensuring an uninterrupted power supply every day.

Key features

Colorful touch LCD: Enhanced user interface with IP65 protection for durability.
6 time periods for battery charging/discharging: Optimized battery management for efficient energy utilization.
Max. 16pcs parallel Scalable design for increased capacity and flexibility.
DC and AC couple compatibility: Retrofit existing solar systems for seamless integration.
48V low voltage battery: Ensures safety and reliability in operation.
Fast transfer from on-grid to off-grid mode: Ensures compatibility with traditional fixed-frequency air conditioners.

Model	SUN-3.6K -SG03LP1-EU	SUN-5K -SG03LP1-EU	SUN-6K -SG03LP1-EU
Battery Input Data
Battery Type	Lead-acid or Lithium-ion
Battery Voltage Range (V)	40-60
Max.Charging Current (A)	90	120	135
Max.Discharging Current (A)	90	120	135
Charging Strategy for Li-ion Battery	Self-adaption to BMS
Number of Battery Input	1
PVString Input Data
Max.DC Input Power (W)	4680	6500	7800
Max.DC InputVoltage(V)	500
Start-up Voltage (V)	125
MPPTVoltage Range(V)	150-425
Rated DC Input Voltage(V)	370
Max.Operating PVInput Current(A)	13+13
Max.Input Short-Circuit Current(A)	17+17
No. of MPP Trackers/ No. of Strings per MPP Tracker	2/1+1
AC Input/Output Data
Rated ACInput/Output Active Power(W)	3600	5000	6000
Max.ACInput/Output Apparent Power(VA)	3960	5500	6600
Rated ACInput/Output Current (A)	16.4/15.7	22.7/21.7	27.3/26.1
Max.ACInput/Output Current(A)	18/17.2	25/23.9	30/28.7
Max. Continuous AC Passthrough (grid to load) (A)	35		40
PeakPower(off-grid)(W)	2 times of rated power,10s
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Rated Input/Output Voltage/Range (V)	220/2300.85Un-1.1Un
RatedInput/Output Grid Frequency/Range(Hz)	50/45-55,60/55-65
Grid Connection Form	L+N+PE
Total Current Harmonic Distortion THDi	<3%(of nominal power)
DC Injection Current	<0.5%In
Efficiency
Max.Efficiency	97.6%
Furo Efficiency	96.5%
MPPT Efficiency	>99%
Equipment Protection
Integrated	DC Polarity Reverse Connection Protection, AC Output Overcurrent Protection AC Output Overvoltage Protection, AC Output Short Circuit Protection, Thermal Protection DC Terminal Insulation Impedance Monitoring, DC Component Monitoring, Ground Fault Current Monitoring Power Network Monitoring, Island Protection Monitoring, Earth Fault Detection, DC Input Switch Overvoltage Load Drop Protection, Residual Current (RCD) Detection, Surge protection level
Surge Protection Level	TYPE II(DC), TYPE II(AC)
Interface
Communication Interface	WIFI,RS485,CAN
General Data
Operating Temperature Range (℃)	-40 to+60℃,>45℃ Derating
Permissible Ambient Humidity	0-100%
Permissible Altitude	2000m
Noise(dB)	<30
Ingress Protection(IP) Rating	IP65
Inverter Topology	Non-Isolated
Over Voltage Category	OVCII(DC),OVCIII(AC)
Cabinet Size(WxHxDmm)	330×580×232 (Excluding Connectors and Brackets)
Weight (kg)	25
Type of Cooling	Intelligent Air Cooling
Warranty	5 Years/10 Years The warranty Period Depends on the Final Installation Site of the Inverter, More Info Please Refer to the Warranty Policy
Grid Regulation	IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105
Safety/EMC Standard	IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
